The SH-anchor system at the end of the round head embedded hanging nail is used for the hook, and the special duckbill buckle spreader is used to achieve a quick hook. The lifting load is transferred to the concrete via a circular end anchor at the other end of the nail. Installation requires the use of hemispherical rubber fixing nails while creating hemispherical grooves on the concrete surface so that the spreader can be hooked and lifted.
The thread lifting system consists of the permanently cast-in lifting anchor---socket anchors and the temporarily connected lifting equipments--lifting loops,rotary head lifting clutchs and cast-in loops.The main products of reinforcement system are Anteky wire loop boxes which are used to connect precast wallpanels to each other, or to a column.
Main Anchors,Nailing plate, lifting devices and wire loop box.
ANTEKY threadbar, together with matching accessories, are used in formwork construction.The coarse thread of threadbar doesnt run around the complete circumference of the bar. Hence the bar is not only insensitive against damages and dirt, but also self-cleaning. The high thread pitch allows a quick assembly and disassembly of the connecting and anchoring parts. And the high strength permites a high load capacity in relation to its low weight per meter.
The fixing system is made up of light duty anchors with low load capacities,mainly used for temporary fixings and applications without structural significance.
Main socket anchors,bolt anchors,bar anchors.
Hollow bolt is a kind of anchor rod made of steel pipe, which is hollow inside, and can be pressurized and anchored by pump slurry through the hollow part. It is often used for system support in tunnel arches and other moderately good geological surrounding rocks.
The wire box system is made of galvanized thin steel metal box and high-strength galvanized steel wire rope, which is suitable for the wall of concrete PC components, and after the wall is placed appropriately, the connecting joints are poured vertically, and the connecting force is directly transmitted from one PC component to another PC component through the connection force between the wire rope and the concrete, so as to ensure the connection firmness of the two PC components.
It is mainly used in double-sided superimposed shear walls, solid walls, sandwich insulation wall panels and other structures. Through the wire rope connection box, these concrete prefabricated parts can be effectively connected, and the stability and safety of the overall mechanism can be enhanced.
> It provides a simple and reliable connection solution that makes the installation of precast concrete parts easier
> The design of the galvanized cartridge and tape cover increases the corrosion resistance of the connecting cartridge and prolongs its service life
> The use of the wire box system can improve the overall performance of the concrete structure, such as crack resistance, durability, etc
